Water Proof Capacitor

Price: 0.59~1.98 USD
Payment Terms: T/T,WU
Place of Origin: Anhui, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: CBB60
Production Capacity: 5000000
Delivery Date: 7 days
Package Type: Throught Hole
Brand Name: Running
Rated Voltage: 110-630VAC
Means of Transport: Ocean,Land,Air
Packing: Carton
Application: AC / Motor
Type: Polypropylene Film Capacito...
Capacitance: 0.5-70uf
Operating Temperature: 40/70/21 or 40/85/21

Water Proof Capacitor
1.Capacitance:0.5-70uf
2.Voltage:110-630VAC

 Water Proof Capacitor
1.Shell: ABS, polypropylene, aluminum
2. Characteristics and Uses: The product has good stability, impact resistance current, overload and strong, low loss, high insulation resistance, long life rated, self-healing performance, built-in flame-retardant epoxy resin filling safe and reliable, capacitor leakage and liquid materials, nontoxic, environmentally and so on. Mainly used in refrigerators, air conditioners, motors, pumps, generators, washing machines, household appliances, electronic products and so on.
3. Technical parameters:
Capacity range: 0.5μF ~ 70μF
Capacity Deviation: ± 5%, or by customer requirements.
Rated voltage: 125V ~ 500VAC, 50/60Hz
Operating temperature range: -25 ℃ ~ +70 ℃
Dissipation factor: ≤ 0.003 (20 ℃ .50/60Hz)
Resistance between terminal voltage: AC ≥ 1.75Un 5S no breakdown
Resistance between terminal voltage and the shell: AC ≥ 2000V 10S no breakdown
Insulation resistance: between terminations Rj · C ≥ 3000MΩ.μF; shell terminal and inter-Rj ≥ 1000MΩ Department
Implementation of the standards: GB/T3667.1-2005 IEC60252-1: 2001.
